Graphics Display Indication
Element Description
Switches between frequency (magnitude) and phase response (phase) indication
Switch for selecting dB-axis scaling of 25 dB (± 12.5 dB) or 50 dB (± 25 dB)
Shows the resulting transfer function of all filter and level trim settings, the visible and audible
result at the sound system processor out- puts. The audible result is displayed in bright colors
while “electrical” graphs are indicated in dark colors.
Selecting ”separate” results in a separated display of the sound system processor channels’
transfer functions while ”sum” shows the summed signal of the sound system processor
channels.
IRIS-Net DIGITAL SOUND PROCESSOR | en 592
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
