DYNAMICS
Each output channel of the sound system processor offers a compressor and a limiter. These functions can be
accessed via the dynamics window to change the corresponding parameters providing reliable protection for the
connected speaker systems against sudden peaks and overload.
Clicking onto the seventh block in the Flow Diagram Selector or double clicking onto the DYNAMICS block in the large
flow diagram opens the dynamics window.
Channel Parameters
Element Description
Channel name
A click with the right mouse button on this field opens the Copy & Paste menu, which allows copying all
dynamics parameters of the corresponding channel to any other channels within the same project.
IRIS-Net DIGITAL SOUND PROCESSOR | en 598
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
