The DSP 600 offers 7 pre-defined configurations. A configuration is a basic setting that
includes the routing of inputs and outputs, the function of the outputs (Sub, Lo, Mid, Hi,
Fullrange), as well as basic X-Over parameters. If you do not want to use one of the pre-
defined configurations, you have also the possibility to operate the DSP 600 in Free
Configuration mode. This mode offers access to all parameters and basically any input/
output routing can be programmed. Additionally, the output assignment (output function -
Sub, Lo, Mid, Hi, Fullrange) is also freely definable.
The DSP 600 defaults to Standard Edit mode wherein input and output channel parameters
are appropriately linked. In Full Edit mode, no parameter links are enforced, regardless of
the configuration selected. When switching from Full Edit mode to Standard Edit mode,
parameters are linked again. At the same time parameters settings in linked channels (upper
numbers) will be over- written.
Recall a Preset
Element
Description
Clicking the RECALL... button opens the Recall Preset dialog, where you can select and recall a Preset.
Caution!
The loaded preset becomes instantly audible when in on-line mode. Be sure to select the desired
preset with the correct set of parameters. In the worst case, this could lead to severe damage to
the connected loudspeaker cabinets due to improper signal processing!
Consequences
