Channel Parameters
Element Default Range Description
Channel name.
A click with the right mouse button opens the ”Copy & Paste” menu, which
allows convenient copying all delay parameters of the corresponding output
to any other delay within the same project.
0 ms 0 to 1000
ms
Delay allows delaying the corresponding output channel’s audio signal by an
adjustable period of time.
Press the ACTIVE button to deactivate the output delay.
General Parameters
Element
Default Range Description
ms ms,
samples,
ft, in, mtr,
cm, µs, s
This lets you select the unit of measurement for the delays.
0
°Celsiu
s
-20 to 60
°C
-4 to 140
°F
Entering the actual ambient temperature is possible here. In
case you have chosen a distance value as unit of
measurement for the delay, delay times are corrected in
relation to temperature. Temperatures can be entered as °C
or °F.
Editing Delays by ”Dragging the Mouse” in the Graphics Display
The graphics display shows the corresponding speaker symbol in color as soon as a delay has been activated. Clicking
with the left mouse button onto the speaker icon and keeping the mouse button pressed allows dragging the symbol to
the right or the left, which results in a change of the selected channel’s delay time. A delay’s title is shown black as
soon as the mouse cursor is positioned on top of the corresponding icon to provide improved overview and handling.
OUTPUT LIMITERS
Each output channel of the sound system processor offers a peak limiter and a TEMP limiter. These functions can be
accessed via the Output Limiters window to change the corresponding parameters providing reliable protection for the
connected speaker systems against sudden peaks and overload.
Clicking on the 12. block (LIM) in the Flow Diagram Selector or double clicking on the SPEAKER PROCESSING
LIMITERS block in the large flow diagram opens the Output Limiters window.
IRIS-Net DIGITAL SOUND PROCESSOR | en 640
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
