Store a Preset
Element Description
STORE saves all currently set DSP parameters together with the entered name into the current preset.
Store is only possible if a user program number is selected.
Clicking the STORE TO.... button opens the Store Preset... dialog. In this dialog the Program Number can
be selected.
Setting a Startup presets
Element
Description
The indicated preset is loaded after power on or reset of the Dx46.
Clicking the ASSIGN .. button opens the Set Initial Preset... dialog. In this dialog a factory preset or user
preset can be selected as startup preset.
Clicking the X buttons clears the Startup preset selection.
IRIS-Net
DIGITAL SOUND PROCESSOR | en 663
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
