Graphics Display Indication
Element Description
Switches between frequency (magnitude) and phase response (phase) indication
Switch for selecting dB-axis scaling of 25 dB (± 12.5 dB) or 50 dB (± 25 dB)
Channel Selection
Element Description
Switch for selecting input A or input B for filter editing and display.
A click with the right mouse button opens the ”Copy & Paste” menu, which allows convenient
copying all EQs of the corresponding output to any other Dx46 Input PEQ filter bank within the
same project.
IRIS-Net DIGITAL SOUND PROCESSOR | en 665
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
