LIMITS OF THE PROMATRIX 8000 SYSTEM
Property DPM 8016 System with n DPM 8016 (n
max
= 10)
Speaker zones, in total 500 1000
– Lines (A/B) per zone 2
Priority relays, in total 1800 3600
– per zone 5
Control relays, in total 1800 3600
– per zone 5
Groups, in total 500
Call stations per PCA port 4
Call stations, in total 16 n * 16
Background music program (without
audio network)
1 n
Remote control amplifiers per DPM 99 n * 99
Amplifier output channels 396 n * 396
Input modules (with two audio
channels each)
8 n * 8
Output modules (with two audio
channels each)
8 n * 8
DCS 801R 15 n * 15
DCS 408R or DCS 409R connected to
a DCS 801R
17 n * 17
DCS 412R connected to a DCS 801R 5 n * 5
DCS 412R, in total 75 n * 75
Logical inputs, in total 500 n * 500 500 n * 500
DCS 416 connected to a DCS 801 5 n *5
DCS 416, in total 75 n * 75
Supervised inputs from a central fire
alarm system
30 n * 30
Relay modules, in total (DCS 408 or
DCS 409)
255 n * 255
Number of relays, in total 2000 n * 2000
Task Engine blocks 1024 n * 1024
Task Engine connections per block 48
Network channels 16
