The Equal block compares the Boolean values at the inputs. The Boolean value at the output is only true
when the values at the inputs are identical (e.g. both inputs are true, or both inputs are false).
The Not Equal block compares the Boolean values at the inputs. The Boolean value at the output is only
true when the values at the inputs are different from each other (e.g. one input is true while the other
input is false).
ADVANCED OPERATIONS
Element Description
The Alarm block is used to trigger an alarm. Double click the block to edit the alarm settings (see
screenshot below).
– PRIORITY: Priority of the alarm (0 to 100).
– ALARM: Select the alarm type to be triggered, see table below.
– INPUT CHANNEL: When using ALARM = EXTERN select the input channel of the DPM 8016,
where the external alarm signal is present.
– DESTINATIONS: Select the destination zone(s) or group(s) for the alarm.
IRIS-Net PROMATRIX 8000 | en 751
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
