Element Description
Local Select this option to use one or more local inputs of UI-1 modules (channel A or
B) as audio source of the selected program.
Shared Select this option to use an existing program of another DPM (connected via
Ethernet) as audio source of the selected program.
CALL STATIONS Select the call stations where the selected program will be listed in the menu.
UserMix Dialog
The UserMix window allows configuring audio routings (e.g. background music) in the PROMATRIX 8000 system.
Element Description
CONDITION The condition that starts the background music, e.g. a switch connected to a GPI of
the device.
INVERT Set the checkbox to invert the condition that starts the back ground music.
IRIS-Net PROMATRIX 8000 | en 768
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
