Bosch IRIS-Net User Manual

MODULES Slot nr. of
faulty
module in
ascending
order
INT-4 Slot nr. of
faulty
module in
ascending
order
Fault INT-4#2 1
„Module fault:#2“
Fault group 5:2 asserted
HARDWARE INT-5 Fault INT-5#1 1
„DPM hardware
fault“
Fault group 4 asserted
TEMPERATUR
E
INT-6 Fault INT-6#1 1
„Temperature
fault“
Fault group 2 asserted
AUDIO
PROCESSING
INT-7 Fault INT-7#1 1
„DSP system
fault“
Fault group 7 asserted
INPUT PILOT
DETEC- TION
Nr. of faulty
input
channel in
ascending
order
INT-8 Nr. of faulty
input
channel in
ascending
order
Fault INT-8#2 1
„Audio In
fault:#2“
Fault group 16:2
asserted
INTERFACES CAN BUS IF-1 Fault IF-1#1 1
„Can bus fault“
Fault group 8 asserted
PCA BUS Slot nr. of
faulty
module in
ascending
order
IF-2 Slot nr. of
faulty
module in
ascending
order
Fault IF-2#2 1
„PCA bus
fault:#2“
Fault group 9 asserted
AUDIO NET IF-3 Fault IF-3#1 1
„AudioNet fault“
Fault group 10 asserted
EXTERNAL DPC DEVICES Address of
faulty DPC
EXT-1 Address of
faulty DPC
Fault EXT-1#2 1
„DPC fault:#2“
Fault group 13:2
asserted
DPA DEVICES Address of
faulty DPA
EXT-2 Address of
faulty DPA
Fault EXT-2#2 1
„DPA fault:#2“
Fault group 12:2
asserted
DCS DEVICES Address of
faulty DCS
EXT-3 Address of
faulty DCS
Fault EXT-3#2 1
„DCS fault:#2“
Fault group 11:2
asserted
POWER
SUPPLY
EXT-4 Fault EXT-4#1 1
„Power fault“
Fault group 19 asserted
SPEAKER LINE
FAULT
Line-Nr. of
faulty line
with 1 to
500: Zone
A, 501 to
1000:
Zone B
EXT-5 Line-Nr. of
faulty line
Fault EXT-5#100 1
„Line fault:#100“
Fault group 16:100
asserted
IRIS-Net PROMATRIX 8000 | en 793
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
