Element Description
MODEL Shows the amplifier type
NAME IRIS-Net internal name of the amplifier
FIRMWARE Shows the amplifier‘s software version number (operating system, firmware)
Opens the firmware update dialog.
PRV / DIR / AEC For each amplifier output channel the signal of the direct input (DIR), the AEC input (AEC) or the
previous input (PREV) can be selected.
The numerical field of the DIRECT input is identical to the numerical field below the level controls
in the Amplifier Control Panel. So the field indicates the actually set attenuation, by which the
internally specified amplification is attenuated, in dB.
The numerical field of the AEC input allows to set the attenuation of this input independently.
IRIS-Net PROMATRIX 8000 | en 821
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
