Bosch IRIS-Net User Manual

DSP Dialog
In this dialog the DSP configuration of the Controller is shown. Double clicking on a DSP-Block’s icon allows editing its
configuration and settings in detail.
Input
The Input block provides access to the audio inputs of the device. The name and gain values of the input channels are
indicated in the block. Double click the block to open the Inputs dialog.
Element
Default Range Description
CST 1 to 4;
MIC/LINE
1,2; AUX 1,2
Permanent channel labeling.
CAN TERM/
STATE
Press the OFF button to activate the internal CAN termination resistor
of the corresponding CST bus. The digit next to the button indicates the
total number of termination resistors activated. The number must
always be “2”.
0.0 dB 0 to 60 dB The gain of the MIC/LINE input channels can be adjusted in 6 dB steps.
IRIS-Net PROMATRIX 6000 | en 842
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
