ADVANCED OPERATIONS
Element Description
The Alarm block is used to trigger an alarm. Double click the block to edit the alarm settings (see
screenshot below).
– PRIORITY: Priority of the alarm (0 to 100).
– ALARM: Select the alarm type to be triggered, see table below.
– INPUT CHANNEL: When using ALARM = EXTERN select the input channel of the DPM 8016,
where the external alarm signal is present.
– DESTINATIONS: Select the destination zone(s) or group(s) for the alarm.
IRIS-Net PROMATRIX 6000 | en 854
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
