Element Description
Destination Clicking onto the button „..." opens the Destinations Dialog for selecting desired Zones and/or
Groups.
Audio Input Select one of the following audio sources for the announcement:
– Internal Mic
– External Mic
– External Line
Locked Behavior
(Active When
Locked)
Selecting this checkbox allows the user to press the button even though the call station has been
locked. The following parameters can be set independently from the default unlocked state.
Trigger Type Select the desired functionality for a button on a call station; available are:
– Push (pushbutton)
– Trigger (triggers a function)
Priority Select the button's priority (0 to 9).
Pre-chime Type Select the desired type of pre-gong (chime) signal. The list includes default signals and chime
signals uploaded to the MM-2 module (if available). Following default signals are available:
– No Prechime
– 1-Tone
– 2-Tone
– 3-Tone
– 4-Tone
– 2x2-Tone
– 2-Tone Pre-Chime
Selection
A switch of the type "Selection" allows configuring a SELECT button. Pressing the button on the call station selects the
Zones and/or Groups that have been configured here.
IRIS-Net
PROMATRIX 6000 | en 897
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
