Supervision Dialog
Element Description
The current condition of each type of error gets indicated. Green means no error, red
indicates that an error has been detected.
NOTIFICATON At the occurrence of a type of error for which the checkbox NOTIFICATON is ticked,
the COMBINED FAULT STATE is set at the same time and the FAULT indicator light at
the Call Station lights.
DEVICE CONNECTED The CST bus connection between Controller and Call Station is broken.
INPUT NUMBER The call station is not connected to the correct CST bus.
MEMORY Memory error in the Call Station.
WATCHDOG + CLEAR Watchdog error in the Call Station. This error type is logged according standards,
press the CLEAR button to reset the error.
FIRMWARE The firmware version of the Call Station is too old.
IRIS-Net PROMATRIX 6000 | en 905
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
