OM-1 MODULE
DEVICE NAME The Device name as indicated by the Dante Controller or the OMNEO Browser.
Cannot be changed and will be set by the controller.
FIRMWARE The OM-1 Module's host application version.
ALLOW UPDATE ALLOW UPDATE switch button is used to update the OM1 firmware and enter the
Access Level 4 password. The OM-1 Module is then set in a state where updates
with the Firmware Upload tool are allowed. Enabled in online mode only.
ERROR DETECTION
OM-1 MODULE Error in OM-1 module of the controller.
OM-1 PRIMARY LINK Primary link up/down.
OM-1 SECONDARY LINK Secondary link up / down.
DANTE SUBSCRIPTIONS Correct static network subscriptions are active.
AUDIO NET COMPLETE Error if at least one controller failed or Ethernet link/DCP connection is down.
SWITCH FAULT 1 User-selectable Supervised or Isolated GPIs for network Switch supervision.
SWITCH FAULT 2 User-selectable Supervised or Isolated GPIs for network Switch supervision.
COLLECTED ERROR This error is indicated as “AUDIO NET” error in the Supervision dialog.
Show Network details
IRIS-Net
PAVIRO | en 960
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
