The specified number of Call Stations will be created and displayed in the worksheet. Selected devices can be dragged
around and repositioned at will. To select a device either click and drag the mouse to draw a rectangle around it or
hold down the 'ctrl' key and click on the device. In either case a successfully selected device is shown with a red
border around it.
Double clicking on a Call Station device icon opens the configuration dialog window. Double clicking on a device for
the first time will open the Configuration dialog box. Here, you can specify initial settings that are necessary for further
configuration and communication. Additional configuration windows can be navigated to by clicking on the icons at the
top of the window. However, as a basic rule, IRIS-Net will remember which window was used last and reopen to this
window next time you double click on the Call Station device icon.
Configuration Dialog
This page allows making basic settings and retrieve information, for example of button functions, network settings,
device name, firmware version, etc.
Element Description
When there are several call stations connected to the CST busses of the
Controller you can select the call station (kit) to configure here.
IRIS-Net PAVIRO | en 970
Bosch Security Systems B.V. User Manual 2017.05 | 3.20 | F.01U.119.956
