7-20
¡
Adding Objects
Setting bar code dimensions
Choose the Dimension tab on the Bar Code screen to set bar code
measurements:
Figure 7-11. The Bar Code screen, Dimensions tab.
Use the Dimension tab to set these bar code options:
Height Set the bar code height (in the unit of
measure specified on the System Setup
screen Localization tab) by entering a
height or choosing from the options list.
Hint! If you want to make a bar code taller,
setting the height here is preferable
to using the Height option on the
Bar Code Size and Location tab.
Density Set the density in mils by choosing from this
list. The density is the thickness of the bars
and how far apart they are.
Hint! This setting determines the width of
the bar code.
