Full HD CMOS Camera System
Communication interface connection (optional accessory)
With the communication interface connection, the LED light source
OP940 can be switched on and to standby via the FULL HD CMOS camera
system - see connection diagrams 1, 2 or 3. In order to use this remote
control of the light source, the communication interface cable OP942
must be connected to the two devices.
Ź Connect the communication interface cable OP942 between the LED
light source OP940 and the camera control unit 11.
Connecting the power supply
Ź Insert the power cord on the rear panel of the camera control unit into
the mains connector 6.
Ź Plug in the mains plug at a socket of the building mains.
Ź Plug in the equipotentialization cable into the equipotentialization
connector 10 of the camera control unit.
Ź Connect the plug of the equipotentialization cable to the building
mains equipotentialization connector.
Ź Make certain that the rear of the device is accessible at all times.
5.2 Function checks
Camera control unit
Ź Check camera control unit for external damage and signs of impact or
other mechanical impacts.
Power cord
Ź Check that the power cord is not broken, kinked or twisted.
Video cable
Ź Check that the video cable is not broken, kinked or twisted.
Camera head with endoscopic lens and camera cable
Note
The endoscopic lens is firmly attached to the camera head and therefore
cannot be removed!
Ź Check that the front glass of endocoupler on the camera head is clean.
If necessary, clean the glass with isopropyl alcohol (70 %).
Ź Make certain that adjusting ring for the focusing ring 18 turns freely
without sticking.
Ź Check that camera cable 26 is not broken, kinked or twisted. Do not
use the camera head in the event of damage.
Ź Check that pins in connection plug 25 are not bent and that there is
no moisture in the plug.
Ź Ensure that the housing of the camera head is not damaged or broken.
Do not use the camera head in the event of damage.
Ź Aim camera head to an object in the room, focus the image and check
for good image quality.
Sterile cover
Note
Aesculap recommends using disposable sterile covers, (e.g. art. no. JG904).
Use of the sterile covers is described in the relevant instructions for use.
Ź Check that the packaging of the sterile covers is unopened, undamaged
and dry before using the sterile covers in the operating room.
DANGER
Risk of fatal injury from electric shock!
Ź Connect the product only to a grounded power
supply.
WARNING
Risk of infection due to soiled or contaminated
products!
Ź Disinfect camera head and camera cable before
each use, or use with sterile cover.
