3
Contents
1. Applicable to 3
2. Safe handling 3
3. Product description 4
3.1 Scope of supply 4
3.2 Components required for operation 4
3.3 Intended use 4
3.4 Operating principle 4
4. Preparation and setup 6
4.1 Preparation 6
5. Working with the camera control unit Full HD PV470 and the
camera head PV471/PV472/PV473 7
5.1 System set-up 7
5.2 Function checks 8
5.3 Safe operation 9
6. Validated reprocessing procedure 14
6.1 General safety instructions 14
6.2 Single-use products 14
6.3 General information 14
6.4 Cleaning/disinfection 15
6.5 Wipe disinfection for electrical devices without sterilization 16
6.6 Manual cleaning/disinfecting 16
6.7 Sterilization 17
6.8 Inspection, maintenance and checks 17
6.9 Packaging 17
6.10 Storage 17
7. Maintenance 17
8. Troubleshooting list 18
8.1 Fuse replacement 19
9. Technical Service 19
10. Accessories/Spare parts 20
11. Technical data 20
11.1 Ambient conditions 21
12. Disposal 21
13. Distributor in the US/Contact in Canada for product
information and complaints 21
1. Applicable to
Ź For item-specific instructions for use and information on material
compatibility, see also the Aesculap Extranet at
www.extranet.bbraun.com
2. Safe handling
CAUTION
Federal law restricts this device to sale by, or on order of a physician!
Ź Manually clean the new product after removing its transport packag-
ing and prior to first use, and disinfect if necessary.
Ź Prior to use, check that the product is in good working order.
Ź Observe “Notes on Electromagnetic Compatibility (EMC)“, see
TA022130.
Ź To prevent damage caused by improper setup or operation, and in order
not to compromise warranty and manufacturer liability:
– Use the product only according to these instructions for use.
– Follow the safety and maintenance instructions.
– Only combine Aesculap products with each other.
Ź Only allow products and accessories to be operated and used by indi-
viduals who have been trained in the use of endoscopic procedures.
Ź Keep the instructions for use accessible for the user.
Ź Always adhere to applicable standards.
Ź Ensure that the electrical facilities in the room in which the device is
being used conform to IEC norms.
Ź Set up the devices in such a way that the ventilation slots at the back
of the device are clear.
Ź Connect the devices to a suitable power source.
Ź Unplug the device by pulling on the plug, and never on the power cord.
Ź In order to avoid damage to the electrical components and inoperabil-
ity:
– Do not bend the product.
– Avoid bending, torsional, tensile or compression loading.
DANGER
Risk of fatal injury from electric shock!
Ź Do not open the product.
Ź Connect the product only to a grounded power
supply.
WARNING
Risk of injury caused by incorrect operation of the
product!
Ź Attend appropriate product training before
using the product.
Ź For information about product training, please
contact your national B. Braun/ Aesculap
agency.
CAUTION
Malfunction in connection with magnetic reso-
nance!
Ź Do not use the product in a magnetic resonance
environment.
