5
Connections on the rear panel of the camera control unit Control element on the camera head with endocoupler
Connector Description
RS232 connector 15 For future applications
USB connector for service pur-
poses 14
Is only used by the manufacturer
for service purposes
Remote connection 13 Connection for remote operation
of peripheral devices (e.g. video
printers) via cables with a 3.5 mm
mono-plug
S-Video output 12 S-Video signal output
Communication interface 11 Connector to connect further
communication interface devices
Equipotentialization connector 10 Connector for equipotentialization
cables acc. to DIN 42801
HD-SDI outputs 9 HD SDI video signal output
(2 connectors)
DVI outputs 8 DVI video signal output (2 connec-
tors)
Fuse holder 7 For standard fuse 0.63 A (T)
Mains connector 6 Connection for power cord
IEC 320, see accessories / spare
parts
Connector Description
Safety lock 16 Prevents inadvertent opening of
endocoupler
Locking mechanism 17 Spring-loaded locking for the
endoscope ocular
Focusing ring 18 Turnable focusing ring
Zoom ring 19 Turnable zoom ring (only PV472)
Button A (up) 20 Function key
Button B (right) 21 Function key
Button D (left) 22 Function key
Button C (down) 23 Function key
Cap 24 Cap to prevent moisture from
entering the plug
Connector plug 25 Connector plug to the camera
control unit
Camera cable 26 Connection cable between the
camera head and camera control
unit
Endocoupler lens Coupler for endoscope ocular
