Port 0 1 2 3 4 5 6 7 8 9
-------------------------------------------------------------------
FID 1 | 1 | 1 | 1 | 1 | 128 | 128 | 128 | 128 | 128 |
<output truncated>
switch:admin>
2. Determine any differences between the information in the SANafter.txt file and the information in the SANbefor.txt file
created earlier. In particular, look for differences in the following:
•
Device types
•
Number of devices
•
ISL and port states
•
Number of switches in the fabric
3. If an SCC policy exists on the active fabric where you are connecting the new chassis, modify the policy to include the
WWN of the new chassis.
•
Refer to the Brocade Fabric OS Administration Guide for information on SCC policy.
•
Use the wwn command to determine WWN of chassis.
•
Use the secPolicyAdd command to modify an existing policy.
4. Resolve any issues or unintentional changes to the device or fabric:
•
If there are any mechanical problems, try reseating the associated component.
•
If the configuration information is not correct for the device, modify as required.
•
If other issues exist, contact your support provider.
Cable routing table
The following table is a 64-port template for a cable routing table. Make copies of the table to cover the total number of
ports in the device.
Table 24: Cable routing table for 64 ports
Slot/port Cable labels Connected device Slot/port of device
Slot Port Switch end Device end
0
1
2
3
4
5
6
7
8
9
10
11
12
13
