53-1002177-19 Hardware Installation Guide Brocade DCX 8510-4 Backbone Hardware Installation Guide
Description Length Corning part number Molex part number Amphenol part number
mSFP LC - standard LC,
duplex, multi-mode, OM3,
50/125
10 m S50502S5120010M 106273-0529 943-99865-10010
Patch cables - mSFP to
mSFP
S5S502S5120XXXM
(XXX = length)
943-99866-1XXXX
(XXXX = length)
mSFP LC - mSFP LC,
duplex, multi-mode, OM3,
50/125
1 m S5S502S5120001M 106273-0560 943-99866-10001
mSFP LC - mSFP LC,
duplex, multi-mode, OM3,
50/125
2 m S5S502S5120002M 106273-0561 943-99866-10002
mSFP LC - mSFP LC,
duplex, multi-mode, OM3,
50/125
3 m S5S502S5120003M 106273-0562 943-99866-10003
mSFP LC - mSFP LC,
duplex, multi-mode, OM3,
50/125
5 m S5S502S5120005M 106273-0563 943-99866-10005
mSFP LC - mSFP LC,
duplex, multi-mode, OM3,
50/125
10 m S5S502S5120010M 106273-0564 943-99866-10010
Trunk cables - mSFP to
MTP
tbd
mSFP LC - MTP-female,
12 fiber, 12" breakout,
OM3, 50/125
H93S5TE9-BMU-XXXM
(XXX = length)
943-99867-1XXXX
(XXXX = length)
mSFP LC - MTP-female,
12 fiber, 6" breakout,
OM3, 50/125
2 m 106272-0327
mSFP LC - MTP-female,
24 fiber, 12" breakout,
OM3, 50/125
2 m 106272-0328
Bag of clips (quantity 64) TRIGGER-BP-NP n/a n/a
High-density cabling for the FC8-64 port blade
The FC8-64 high density port blade cannot use the standard LC cables because the pitch between optics in the new mini-
SFP (mSFP) transceiver is smaller than in standard SFPs. Patch cables and panels can be used to attach standard size
cabling to the blade if necessary. The following figure illustrates the mSFP to SFP patch cable. Refer to "Best Practices
Guide: High Density Cable Management Solutions" (available at http://www.brocade.com ) for cable management
guidelines for high-density port solutions, and cable and patch panel part numbers.
53-1002177-19
64
