53-1002177-19 Hardware Installation Guide
Brocade DCX 8510-4 Backbone Hardware Installation Guide
FC16-64 port blade LEDs
Figure 45: FC16-64 port blade LEDs
1. Blade status LED
2. Blade power LED
3. Port status LED for FC port 36
4. QSFP port 9; FC ports 36-39 (right to left)
FS8-18 encryption blade LEDs
Figure 46: FS8-18 encryption blade LEDs
1. Blade status LED
2. Blade power LED
3. Fibre Channel port
4. Port status LED
53-1002177-19
88
