Broadcom Brocade DCX 8510-4 Backbone User Manual

53-1002177-19 Hardware Installation Guide Brocade DCX 8510-4 Backbone Hardware Installation Guide
LED purpose Color Status Recommended action
Slow-flashing amber (on 2
seconds, then off 2 seconds)
Port is disabled due
to diagnostic tests
or portDisable or
portCfgPersistentEnable
command.
Reset the port from
the workstation using
the portEnable or
portCfgPersistentEnable
command.
Fast-flashing amber (on 1/2
second, then off 1/2 second)
Transceiver or port is faulty. Change the transceiver or reset
the switch from the workstation.
Alternating green/amber Port is bypassed. Reset the port from
the workstation using
the portEnable or
portCfgPersistentEnable
command.
GbE and 10-GbE ports status LED description
The following table describes blade GbE and 10-GbE port status LED patterns and the recommended actions for those
patterns.
Table 15: 1-GbE and 10-GbE port status LED description
LED purpose Color Status Recommended action
No light (LED is off) Port has no incoming power, or
there is no light or signal carrier
detected.
Verify that the power LED is on,
check the transceiver and cable.
Steady green Port is online but has no traffic. No action required.
Slow-flashing green (on 1
second, then off 1 second)
Beacon. Used to identify specific
ports.
No action required.
Flickering green Port is online, with traffic flowing
through port.
No action required.
GbE Port Status both 1-GbE
and 10-GbE ports
Fast-flashing amber (on 1/4
second, then off 1/4 second)
Transceiver or port is faulty. Change the transceiver or reset
the switch from the workstation.
53-1002177-19
91
