53-1002177-19 Hardware Installation Guide
Brocade DCX 8510-4 Backbone Hardware Installation Guide
DANGER
Use safe lifting practices when moving the product.
CAUTION
To prevent damage to the chassis and components, never attempt to lift the chassis using the fan or power
supply handles. These handles were not designed to support the weight of the chassis.
CAUTION
Never leave tools inside the chassis.
DANGER
Make sure the rack housing the device is adequately secured to prevent it from becoming unstable or falling
over.
Unpacking, transporting, and installing the device
Use the following procedure to unpack and install your device.
DANGER
A fully populated chassis (four FC16-64 port cards, 256 ports) weighs approximately 69.5 kg (153 lbs) and
requires a hydraulic or assisted lift to install it.
1. Unpack the device.
a) Cut the bands that encircle the packaging.
b) Remove the lid and the kits and foam from the top of the chassis.
c) Lift the cardboard box off the chassis and remove the plastic bag from around the chassis.Save the packing
materials for use when returning the old chassis.
d) Leave the chassis on top of the plastic shipping tray if the chassis must be transported to the installation location.
NOTE
The device packaging does not incorporate a wood pallet and pallet brackets. The chassis sits on top of
a plastic shipping tray.
2. Use a pallet jack or other assisted lift to transport the new chassis to the installation area. Doorways must be wider
than 36 in. (91 cm) to accommodate the chassis.
3. Remove the following items from the chassis and set aside.
•
Brocade DCX 8510-4 Airflow Diversion and Port Side Exhaust Kit (if ordered)
•
Accessory kit
•
Packing foam
•
Antistatic plastic
