53-1002177-19 Hardware Installation Guide Brocade DCX 8510-4 Backbone Hardware Installation Guide
Table 13: Port and application blades status LED description
LED purpose Color Status Recommended action
No light (LED is off) Blade is either healthy or does
not have power.
Verify that the power LED is on.
Steady amber Blade is faulty. Ensure that the blade is firmly
seated and check the status
by entering the slotShow
command. If LED remains
amber, consult the device
supplier.
Slow-flashing amber (on 2
seconds, then off 2 seconds)
Blade is not seated correctly or
is faulty.
Pull the blade out and reseat
it. If LED continues to flash,
replace the blade.
Status LED
Fast-flashing amber (on 1/2
second, then off 1/2 second)
Environmental range exceeded. Check for out-of-bounds
environmental condition and
correct it.
FC ports status LED description
The following table describes blade FC ports status LED patterns and the recommended actions for those patterns.
Table 14: FC ports status LED description
LED purpose Color Status Recommended action
Port has no incoming power, or
there is no light or signal carrier
detected.
Verify that the power LED is on,
check the transceiver and cable.
Polling is in progress. Allow 60 seconds for polling to
complete.
No light (LED is off)
Connected device is configured
in an offline state.
Verify the status of the
connected device.
Steady green Port is online (connected to
an external device) but has no
traffic.
No action required.
Slow-flashing green (on 1
second, then off 1 second)
Port is online but segmented,
indicating a loopback plug or
cable or an incompatible switch.
Verify that the correct device is
attached to the chassis.
Fast-flashing green (on 1/4
second, then off 1/4 second)
Port is in internal loopback
(diagnostic).
No action required.
Flickering green Port is online, with traffic flowing
through port.
No action required.
FC Port Status
Steady amber Port is receiving light or signal
carrier, but it is not online yet.
Reset the port from
the workstation using
the portEnable or
portCfgPersistentEnable
command.
53-1002177-19
90
