53-1002177-19 Hardware Installation Guide
Brocade DCX 8510-4 Backbone Hardware Installation Guide
Description Quantity
Duct 1
Shelf 1
Shelf saddle 1
10-32 x .5 in. (1.27 cm) Phillips screw (blue Loctite on threads) 12
10-32 x .63 in.(1.60 cm) Phillips screw with square-cone washer 12
10-32 clip nut for racks that have rails with round holes 8
10-32 retainer nut for racks that have rails with square holes 8
Alignment washer for racks that have rails with square holes 12
6-32 x .25 in. (.635 cm) Phillips screw 2
Figure 11: Airflow Diversion and Port-Side Exhaust Kit assembly for 18-24 in. (45.72 to 60.96 cm) racks
1. Top rail
53-1002177-19
36
Broadcom
