203
POWERHEAD
POWERHEAD DISASSEMBLY
10
Inspect the crankshaft sleeve and replace if nec-
essary. To remove the sleeve, use Slide Hammer,
P/N 432128, and Large Puller Jaws, P/N 432129.
Remove the lower main bearing only if it needs to
be replaced. Use external retaining ring pliers to
remove the lower bearing retaining ring.
IMPORTANT: If the lower main bearing is
removed from the crankshaft, it must be dis-
carded. DO NOT reuse it.
Use a bearing separator to support the bearing,
and press off the crankshaft.
Remove center main bearings and split sleeves
for inspection. DO not mix parts. Note location of
bearings for reassembly.
002041
002039
002052
24381
