54
ENGINE COVER SERVICE
UPPER COVER SERVICE
UPPER COVER SERVICE
Latch Hook Installation
Insert threaded bracket into pocket.
Apply Ultra-Lock to screw threads. Place hook
into position with opening toward the front. Tighten
screws to a torque of 60 to 84 in. lbs. (7 to 9.5
N·m).
LOWER COVER SERVICE
Lower Cover Removal
Remove lower engine cover screws.
Loosen port side cover slightly, and disconnect
trim/tilt switch connector. Then, remove port and
starboard covers.
1. Bracket 006468
006469
1. Lower cover screws 002168
1. Trim/tilt switch connector 002169
To Next Page
