246
MIDSECTION
EXHAUST HOUSING, 40 – 60 HP
EXHAUST HOUSING,
40 – 60 HP
The exhaust housing contains no serviceable
internal parts. The exhaust water valve and the
exhaust relief muffler can both be serviced without
removing the exhaust housing.
Exhaust Housing Removal
Before removing the exhaust housing:
• Remove the gearcase. Refer to Gearcase
GEARCASE REMOVAL AND INSTALLATION
on p. 292.
• Remove the powerhead. Refer to Powerhead
POWERHEAD REMOVAL on p. 194.
Remove the three lower mount cover screws.
Separate lower mount covers from swivel bracket.
Check condition of the lower front mount and two
lower side mounts.
Remove the three upper mount to exhaust hous-
ing screws. Be sure to support exhaust housing
so it does not fall.
Remove the exhaust housing.
17527
1. Lower front mount 17526
1. Lower side mount 17524
COA2943
Exhaust Housing 005069
