75
ENGINE MANAGEMENT MODULE (EMM)
EMM SERVICING
4
Installation
Installation is the reverse of removal. Pay close
attention when performing the following tasks.
Make sure isolator mounts are placed in slots in of
EMM case. Slide EMM into position.
Apply Nut Lock to threads of EMM retaining
screws. Tighten to a torque of 30 to 42 in. lbs. (4
to 5 N·m).
Install harness connectors and cooling hoses.
Secure hoses with tie straps.
1. Isolator mounts 006478
To Next Page
