41
ROUTINE SERVICE
LUBRICATION
2
LUBRICATION
Steering System
Grease the stainless steel output end of the steer-
ing cable with Triple-Guard grease.
Use an appropriate cleaning solvent to remove
corrosion and dirt from output end of cable before
coating it with grease. Make sure wiper nut is
installed and not damaged.
Tiller Handle
Lubricate the tiller handle grease fittings with Tri-
ple-Guard grease.
A WARNING
Failure to regrease as recommended
could result in steering system corrosion.
Corrosion can affect steering effort, mak-
ing operator control difficult.
1. Steering cable
2. Wiper nut
DR29546
1. Tiller handle fittings – Standard handle 008196
1. Tiller handle fittings – Long handle 008197
