361
TRIM AND TILT
TRIM AND TILT SERVICE
13
Fill the oil reservoir up to the fill plug with
Evinrude/Johnson Biodegradable TNT Fluid.
Install the fill plug.
Run the motor, then recheck oil level. Cycle the
unit several times and check the oil level when the
cylinder is fully extended. Oil should be level with
bottom of fill port. Install and tighten the fill plug to
a torque of 45 to 55 in. lbs. (5 to 6 N·m).
Refer to Installation on p. 350 for trim and tilt
assembly installation procedure.
40 - 60 HP Models 007646
75 - 90 HP Models 004278
