13
Sample Heater
Option 13
General Information 13.1
The B-ACS SAMPLE HEATER 120C (figure 13.2) is used in connection with the
BRUKER AUTOMATIC SAMPLE CHANGER (B-ACS 60, B-ACS 120) for NMR
Spectrometer‘s.
Using the B-ACS Sample Heater it is possible to preheat NMR probes to a range
of +30°C and +120°C depending upon the ambient temperature.
Prerequisites 13.1.1
Before installing the SAMPLE HEATER, the following points must be observed:
The B-ACS LIGHT BARRIER MAGAZINE.
The new Sample Changer must have a new version of the Light Barrier Magazine.
If this is not the case, it must be exchanged for our new one, because the Maga-
zine belt will not turn with the Sample Heater using the old Light Barrier.
Therefore if you are using the old version B-ACS 60 Part No. H1082, or the old
version B-ACS 120 Part No. H655, you will need to replace it with the new version
B-ACS 60 / Part No. H1402, or the B-ACS 120 Part No. H1403.
In addition, a sliding ring for transmission from the DC power supply, must be
placed directly under the cabinet (see figure 13.1
).
