Bruker B-ACS 60 - Figure A.3. Overview of the Sample Changer on a Magnex Magnet

148 (167) BRUKER Installation Manual Version 001
Figure A.3. Overview of the Sample Changer on a Magnex Magnet
CABINET
MAGNET
MAGAZINE BELT
PINCHER
VERTICAL
CYLINDER
PISTON
FIXTURE
RINGS
PNEUMATIC ARM
RESTING RING
TOP FASTENING
RING
PNEUMATIC ARM
BASE PLATE
COLUMN LEGS
COLUMN
ADJUSTABLE ARM
ASSEMBLY
N2 TOWER
KST 25.09.96 MAGNEX02.DS4
