General Information
Installation Manual Version 001 BRUKER 133 (167)
Warning: Do not insert your fingers into the samples heater. When the sample
heater is operating it can reach temperatures exceeding 120°C.
Start-up 13.1.5
The B-ACS Sample Heater 120C operates between +30°C and 120°C.
After switching on the power supply, the green LED, in front of the Sample Heater,
should be on.
The adjustment of nominal temperature is accomplished using the middle knob on
the lower position of the heater.
The red LED displays the heater condition.
Test conditions 13.1.6
• Sample tube 10mm
• Filled with oil to a height of 65mm
• Temperature measured with digital thermometer
Table 13.2. Test measure
Position of tuning knob Oil temperature reached
30°C 30°C
60°C 59°C
90°C 92°C
120°C 122°C
