Installation Manual Version 001 BRUKER 145 (167)
Magnex Magnets A
Introduction A.1
This is a supplement to the BRUKER Automatic Control Systems installation man-
ual - mounting instructions (chapter 4) for the mounting of a sample changer on a
Magnex Magnet.
Mounting Instructions A.2
Preparation A.2.1
Prepare the light barrier assembly, cabinet and column assembly as described in
the chapter 2 of the BRUKER Automatic Control Systems installation manual.
Mounting the Base Plate A.2.2
Connect the adjustable arm assemblies to the round column part just below the
cabinet, and tighten it loosely.
Remove the holding screw that will hold the base plate to the magnet (refer to fig-
ure A.1). Place the base plate on the rim of the magnet and fasten it using the
base plate adjustment screw (refer to figure A.2). Do not tighten the screw com-
pletely, allow some movement for adjustments.
