General Information
Installation Manual Version 001 BRUKER 131 (167)
Installation 13.1.2
To install the sample heater, the following procedures must be performed:
Snap the Sample Heaters directly onto the Magazine Belt.
Note: When using the B-ACS 120 Sample Changer, use the inside chain posi-
tions for installation of the heaters. The outside positions, next to the positions
used for the heaters, can not be used for samples as this would result in the
PWR24 cables being disturbed.
Connect the heaters together using PWR24 cable (Part No. H1484), the first heat-
er to the second, the second heater to the third, and so on forming a chain as illus-
trated in figure 13.2
.
The B-ACS Heater Supply 2 figure 13.2
has a fixed pin inside to signify a busy
position.
If you are installing the maximum number of heaters (30), then the Heater Supply
2 (Part/No. H5806) should be positioned in the middle, leaving 15 samples on
each side of the supply chain.
Connect the Power Supply (Part/No. H1455) to the sliding ring (Part/No. H5886)
under the cabinet using the enclosed cable (figure 13.1
).
Connect the sliding ring (Part/No. H5886) to the Heater Supply 2 (figure 13.1
).
The Power Supply, should be placed a minimum of 2 meters away from the mag-
net.
Operating instructions 13.1.3
After switching on the power supply, the green LED in front of the Heater Supply
should be on. The adjustment of the nominal temperature is accomplished by us-
ing the milled knob on the lower position of the heater.
The desired temperature (look on the knob) is selected by aligning the required
scale value with the white marker on the heater.
The red LED displays the heater condition.
During the heating cycle the red LED should be on.
After reaching the selected temperature, the red LED should turn off.
LED ON signifies heating cycle.
LED OFF signifies that the nominal temperature has been reached
