Bruker B-ACS 60 - Figure A.2. Base Plate and Adjustable Arm Assembly

Installation Manual Version 001 BRUKER 147 (167)
Figure A.2. Base Plate and Adjustable Arm Assembly
CABINET
MAGAZINE BELT
TOP FASTENING
RING
BASE PLATE
BASE PLATE SUPPORT
HEX NUT M8
WASHER
PLANE M8
BASE PLANE
COLUMN
COLUMN LEGS
SCREW M6X30
ADJUSTMENT
ADJUSTMENT SCREW
MAGNET
MAGNET
TOP FASTENING
RING
ADJUSTABLE ARM
ASSEMBLY
COLUMN
N2 TOWER
ADJUSTMENT
SCREW M6X30
KST 25.09.96 MAGNEX03.DS4
STAND COLUMN
PLATE
