Installation Manual Version 001 BRUKER 57 (167)
9
Operator
Maintenance 9
Greasing the Horizontal Arm 9.1
The horizontal arm should be lubricated bi-annually (at least) with B-ACS grease
P/N H5043 (has a clear-white color) to allow for smooth operation.
Greasing the Vertical Cylinder 9.2
The moving parts of the vertical cylinder should be lubricated bi-annually (at least)
with B-ACS grease P/N H5042 (has a light brown color) to allow for smooth up
and down movement.
Arm Adjustment 9.3
The arm should be adjusted initially, and rechecked periodically to ensure that the
samples are being properly grasped by the pincher. Refer to chapter 5, Settings
and Adjustments.
Cabinet Adjustment 9.4
The cabinet will need adjusting if the sample, when approaching the magazine
belt, is not centered perfectly in the sample holder of the magazine belt. If the in-
ward position of the vertical cylinder is not correct, then refer to the chapter 5, Set-
tings and Adjustments. If the spinner tip edge gets too close to the sample holder
(less than 5 mm) move the cabinet downwards on the column (refer to chapter 5l,
Settings and Adjustments). The correct distance between the spinner top edge
and the magazine belt should be approximately 5 mm.
Vertical Cylinder 9.5
The vertical position of the vertical cylinder is factory set and does not need ad-
justing. The horizontal position can be adjusted by loosening the two screws un-
der the bottom support bracket of the vertical cylinder (refer to chapter 5, Settings
and Adjustments).
