2-40 2002 Buell P3: Chassis
HOME
5. See Figure 2-61. Remove the spring collar, lower spring
seat and spring from slider tube.
6. See Figure 2-62. Remove the fork oil by pumping the
fork leg and rod 8-10 times until the rod moves freely.
7. See Figure 2-63. Remove the center bolt (metric) from
the bottom of the fork tube.
Figure 2-61. Removing Sub-Assembly
Figure 2-62. Pumping Fork Oil
Figure 2-63. Removing Center Bolt
1. Spring Collar
2. Lower Spring Seat
3. Spring
a0006xSx
1
2
3
3770
3771
