2-44 2002 Buell P3: Chassis
HOME
5. See Figure 2-73. Clamp the slider assembly in a vise
with front fork holding tool (part no. B-4177).
6. See Figure 2-74. Install slider tube into slider assembly.
CAUTION
The outer tube can move freely up and down on the slide
pipe. Always hold both the slide pipe and outer tube to
prevent damage to bushings and seals.
7. See Figure 2-75. Install spring onto damper assembly.
Figure 2-73. Clamping the Slider Assembly
Figure 2-74. Slider Tube
Figure 2-75. Install Rebound Spring
3792
3790
3796
