2002 Buell P3: Drive/Transmission 6-27
HOME
Figure 6-41. Transmission Assembly Left Crankcase Half
1. Mainshaft Nut
2. Spring Washer
3. Retaining Ring
4. Bearing
5. Left Crankcase Half
6. Mainshaft
7. Spacer
8. Bearing (4)
9. Fourth Gear Mainshaft
10. Thrust Washer (6)
11. Retaining Ring (7)
12. First Gear Mainshaft
13. Third Gear Mainshaft
14. Second Gear Mainshaft
15. Spacer
16. Fourth Gear Countershaft
17. First Gear Countershaft
18. Countershaft
19. Third Gear Countershaft
20. Second Gear Countershaft
21. Fifth Gear Countershaft
22. Bearing
23. Retaining Ring
24. Countershaft Retainer
25. Screw
a0126x6x
16
15
5
4
3
2
1
22
23
24
25
11
10
11
21
20
8
10
11
19
18
11
10
17
8
14
11
10
13
8
10
11
12
11
10
9
8
7
6
