7-30 2002 Buell P3: Electrical
HOME
2. Test the switch using an ohmmeter.
a. With clutch engaged (1) (switch open), the switch
should show ∞ ohms (infinite ohms).
b. With clutch disengaged (2) (switch closed), the
switch should show 0 ohms or little resistance.
3. Replace the assembly with a new switch if necessary.
a. Remove small Phillips screw.
b. Depress clutch lever and hold.
c. Detach switch by depressing switch trigger button
and pulling switch towards the end of the handlebar.
d. Install new switch.
NOTE
To test/replace the neutral switch, see 7.23 NEUTRAL INDI-
CATOR SWITCH.
Figure 7-33. Side Stand Switch
Figure 7-34. Clutch Switch
a0230x7x
Connector [60]
Sidestand
Switch
Screw (2)
30-36 in-lbs
(3.3-4.1 Nm)
Nut (2)
a0231x7x
1. Clutch Engaged (switch open)
2. Clutch Disengaged (switch closed)
3. Connector [95]
Trigger
Button
3
1
2
