büS/CAN open-Design

→ Inthenewwindow“NewModule”,enter

anewsignicantnameinthenameeld

and select the appropriate “Private

Network”numberforthe“Ethernet

Address”

→ Clickon“OK”button

→ Closethe(old)window“SelectModule

Type”

→ in the new window DOWNLOAD the

correspondingles(seechapter“15.10

Gateway”onpage92)ontothePLC

→ Then“GoOnline”toconnectthe

gateway and the master controller / PLC

(EtherNet/IP)toeachother
