AS Interface - Design
12.9 Programming data
ThecontrolheadshavebeenconguredasASinterfaceversionwithanextendedaddressrange(A/B
slaves)for62slavesoroptionallyasanASinterfaceversionfor31slaves.
A change between both control head congurations (for 62 slaves or 31 slaves) is only pos-
sible by exchanging the electronic PCB!
IfonecontrolheadisreplacedwithanothercontrolheadhavingadierentcongurationintheAS
interfaceeldbussystem(e.g.ASinterfaceversion62slaves(A/B-Slave)toreplaceadevicewithAS
interfaceversion31slaves),acongurationerrorwillbegeneratedatthemasterduetothedierent
ID codes!
Inthiscase(intentionalreplacement!),thecurrentcongurationmustbere-programmedintheAS
interface master. Please read the operating instructions of the used AS interface master!
AS-i address factory setting:
AS-iaddress=0
Programming data table:
Programming data for 62 slaves
ASinterface-DeviceforA/Bslave
addressing(defaultdevice)
Programming data for 31 slaves
ASinterface(optional)
I/Oconguration 7hex(4inputs/4outputs)
seebelow:Bitcongurationtable
7hex(4inputs/4outputs)
seebelow:Bitcongurationtable
ID code A hex F hex
Extended ID code 1 7 hex
(Fhex)
Extended ID code 2 E hex (Fhex)
Prole S-7. A.E S-7. F.F
Bit conguration table:
Data bit D3 D2 D1 D0
Input External initiator
S4
Position S3 Position S2 Position S1
Output Not used Solenoid valve V3 Solenoid valve V2 Solenoid valve V1
Parameter bit P3 P2 P1 P0
Output Not used Not used Not used Not used
Comparealsothebitcongurationforthedesign“19.2Controlhead(AS-i)with2externalinitiators”onpage128.
