6.3 Type label
Thespecicationsonthetypelabelindicatethetechnicaldataandapprovalsapplicabletotherespective
controlhead.Thesymbolsonthetypelabel(example)mean:
Type label
Line 1
Line 2
Line 3
Line 4
Line 5
Line 6
Line 7
Line 1 Device type
Line 2 Device design:
Typeofcommunication(24VDC,120VAC,AS-i,DevNet,IO-Link,büS/CANopen);
(possiblysupplyvoltage);
Numberofsolenoidvalves(“MV”):
MV0=nosolenoidvalve,
MV1=1solenoidvalve,single-action,
MV2=2solenoidvalves,notdouble-acting,
MV3=3solenoidvalves,
MVD=2solenoidvalves,double-acting)
Line 3 Permitted pressure range
Line 4
Permittedambienttemperaturerange(Tamb)
(furtherdevicespecicinformationpossible)
Line 5 Serial number S/N
Line 6 ID number
/dateofmanufacture(coded)
Line 7 Barcode(withIDandserialnumber)
Further symbols and information on the type label indicate special approvals or relevant
approval information for this device
Further possible symbols on the type label:
Device complies with European standards according to EU Declaration of Conformity
Approvalaccordingto(potentiallyexplosiveatmospheres)“ATEX”Directive
FMapprovalforexplosion-proofequipment
UL approval for USA and Canada
