Assembly

Electrical installation

Electrical installation and the communication connections depend on the control head variant:

24 V DC: see chapter “1024VDC-Design”,

120 V AC: see chapter “11120VAC-Design”

AS interface: see chapter “12ASInterface-Design”,

DeviceNet: see chapter “13DeviceNet-Design”,

IO-Link: see chapter “14IO-Link-Design”,

büS/CANopen: see chapter “15büS/CANopen-Design”.

7.2.5 Recommended auxiliary materials

Silicone grease for easy lubrication of the EPDM seals.
