15.17 Installation of a gateway via Logix Designer
Gateway(s)mustbeaddedtotheEthernet(I/OConguration):
→ Startthe“LogixDesigner”
→ First,go“Oine”
→ Searchfor “I/O Configuration”and
“Ethernet”
→ Rightclickon“Ethernet”
→ Select“NewModule”
→ In the new window “Select Module
Type”,selecttheappropriatedevicefrom
the“Catalogue”:
(usethelterfunctionforafastersearch:
vendor“BuerkertWerke...”)
→ After selecting the “Gateway 8681
bueS”,clickonthe“Create”button
(continuedonnextpage)
